Serial Interface Register Maps
Table 2-1092. Register 138 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG16[7:0]
R 0h
Macro result register # 16. Interpretation of the contents of this
register depend on the last macro command
2.8.154 Register 139h (offset = 139h) [reset = 0h]
Figure 2-1085. Register 139h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG16[15:8]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1093. Register 139 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG16[15:8]
R 0h
Macro result register # 16. Interpretation of the contents of this
register depend on the last macro command
2.8.155 Register 13Ah (offset = 13Ah) [reset = 0h]
Figure 2-1086. Register 13Ah
7 6 5 4 3 2 1 0
MACRO_RESULT_REG16[23:16]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1094. Register 13A Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG16[23:16]
R 0h
Macro result register # 16. Interpretation of the contents of this
register depend on the last macro command
2.8.156 Register 13Bh (offset = 13Bh) [reset = 0h]
Figure 2-1087. Register 13Bh
7 6 5 4 3 2 1 0
MACRO_RESULT_REG16[31:24]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1095. Register 13B Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG16[31:24]
R 0h
Macro result register # 16. Interpretation of the contents of this
register depend on the last macro command
