Serial Interface Register Maps
2.6.36 Register 4061h (offset = 4061h) [reset = 0h]
Figure 2-750. Register 4061h
7 6 5 4 3 2 1 0
EYE_MARGIN_VAL[11:8]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-756. Register 4061 Field Descriptions
Bit Field Type Reset Description
3-0
EYE_MARGIN_VA
L[11:8]
R 0h Eye Margin read back value.
2.6.37 Register 4062h (offset = 4062h) [reset = 0h]
Figure 2-751. Register 4062h
7 6 5 4 3 2 1 0
DFE_F1_VALUE
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-757. Register 4062 Field Descriptions
Bit Field Type Reset Description
6-0 DFE_F1_VALUE R 0h DFE F1 read back value.
2.6.38 Register 4065h (offset = 4065h) [reset = 0h]
Figure 2-752. Register 4065h
7 6 5 4 3 2 1 0
CDR_BW_VAL
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-758. Register 4065 Field Descriptions
Bit Field Type Reset Description
7-5 CDR_BW_VAL R 0h TIMING LOOP CDR BW readback value.
2.6.39 Register 4066h (offset = 4066h) [reset = 0h]
Figure 2-753. Register 4066h
7 6 5 4 3 2 1 0
LINK_RESTART_CNTR
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-759. Register 4066 Field Descriptions
Bit Field Type Reset Description
3-0
LINK_RESTART_C
NTR
R 0h Readback value for the link restart counter.
