Texas Instruments AFE79 Series User Manual

IO Wrap Register Map www.ti.com
1246
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
2.16.750 Register 182Dh (offset = 182Dh) [reset = 0h]
Figure 2-3013. Register 182Dh
7 6 5 4 3 2 1 0
READ_INTPI_
RXA_ALC_INP
UT_2_B1
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3029. Register 182D Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXA
_ALC_INPUT_2_B
1
R 0h read only register for function intpi_rxa_alc_input_2_b1
2.16.751 Register 182Eh (offset = 182Eh) [reset = 0h]
Figure 2-3014. Register 182Eh
7 6 5 4 3 2 1 0
READ_INTPI_
RXB_ALC_INP
UT_0_B1
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3030. Register 182E Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXB
_ALC_INPUT_0_B
1
R 0h read only register for function intpi_rxb_alc_input_0_b1
2.16.752 Register 182Fh (offset = 182Fh) [reset = 0h]
Figure 2-3015. Register 182Fh
7 6 5 4 3 2 1 0
READ_INTPI_
RXB_ALC_INP
UT_1_B1
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3031. Register 182F Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXB
_ALC_INPUT_1_B
1
R 0h read only register for function intpi_rxb_alc_input_1_b1
