2.6.179 Register 7E04h (offset = 7E04h) [reset = 0h]
Figure 2-893. Register 7E04h
7 6 5 4 3 2 1 0
FIRMWARE_DATA2[7:0]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-899. Register 7E04 Field Descriptions
Bit Field Type Reset Description
7-0
FIRMWARE_DATA
2[7:0]
R/W 0h
Firmware word holding register.
When this register is used for eye diagram data, access is
read only and the value depends on the data written to the
register.
2.6.180 Register 7E05h (offset = 7E05h) [reset = 0h]
Figure 2-894. Register 7E05h
7 6 5 4 3 2 1 0
FIRMWARE_DATA2[15:8]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-900. Register 7E05 Field Descriptions
Bit Field Type Reset Description
7-0
FIRMWARE_DATA
2[15:8]
R/W 0h
Firmware word holding register.
When this register is used for eye diagram data, access is
read only and the value depends on the data written to the
register.
2.6.181 Register 7E06h (offset = 7E06h) [reset = 0h]
Figure 2-895. Register 7E06h
7 6 5 4 3 2 1 0
FIRMWARE_DATA3[7:0]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-901. Register 7E06 Field Descriptions
Bit Field Type Reset Description
7-0
FIRMWARE_DATA
3[7:0]
R/W 0h
Firmware word holding register.
When this register is used for eye diagram data, access is
read only and the value depends on the data written to the
register.
