2.8.101 Register 104h (offset = 104h) [reset = 0h]
Figure 2-1032. Register 104h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG3[7:0]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1040. Register 104 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG3[7:0]
R 0h
Macro result register # 3. Interpretation of the contents of this
register depend on the last macro command
2.8.102 Register 105h (offset = 105h) [reset = 0h]
Figure 2-1033. Register 105h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG3[15:8]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1041. Register 105 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG3[15:8]
R 0h
Macro result register # 3. Interpretation of the contents of this
register depend on the last macro command
2.8.103 Register 106h (offset = 106h) [reset = 0h]
Figure 2-1034. Register 106h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG3[23:16]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1042. Register 106 Field Descriptions
Bit Field Type Reset Description
7-0
MACRO_RESULT_
REG3[23:16]
R 0h
Macro result register # 3. Interpretation of the contents of this
register depend on the last macro command
2.8.104 Register 107h (offset = 107h) [reset = 0h]
Figure 2-1035. Register 107h
7 6 5 4 3 2 1 0
MACRO_RESULT_REG3[31:24]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
