Serial Interface Register Maps
2.6.191 Register 7E10h (offset = 7E10h) [reset = 0h]
Figure 2-905. Register 7E10h
7 6 5 4 3 2 1 0
FIRMWARE_DATA8[7:0]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-911. Register 7E10 Field Descriptions
Bit Field Type Reset Description
7-0
FIRMWARE_DATA
8[7:0]
R/W 0h
Firmware word holding register.
When this register is used for eye diagram data, access is
read only and the value depends on the data written to the
register.
2.6.192 Register 7E11h (offset = 7E11h) [reset = 0h]
Figure 2-906. Register 7E11h
7 6 5 4 3 2 1 0
FIRMWARE_DATA8[15:8]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-912. Register 7E11 Field Descriptions
Bit Field Type Reset Description
7-0
FIRMWARE_DATA
8[15:8]
R/W 0h
Firmware word holding register.
When this register is used for eye diagram data, access is
read only and the value depends on the data written to the
register.
2.6.193 Register 7E12h (offset = 7E12h) [reset = 0h]
Figure 2-907. Register 7E12h
7 6 5 4 3 2 1 0
FIRMWARE_DATA9[7:0]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-913. Register 7E12 Field Descriptions
Bit Field Type Reset Description
7-0
FIRMWARE_DATA
9[7:0]
R/W 0h
Firmware word holding register.
When this register is used for eye diagram data, access is
read only and the value depends on the data written to the
register.
