Serial Interface Register Maps
Table 2-2642. Register 4F4 Field Descriptions (continued)
Bit Field Type Reset Description
1-0
BUF_DIR_CTRL_G
PIO_61
R/W 1h
Controls the direction of GPIO
0 both input and output are not selected.. can be used for
analog
1 input mode
2 output mode
3 shouldnt be used
2.16.364 Register 4F7h (offset = 4F7h) [reset = 0h]
Figure 2-2627. Register 4F7h
7 6 5 4 3 2 1 0
ACTIV_BIR_DIR_CTRL_GPIO_61 reserved
R/W-0h R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2643. Register 4F7 Field Descriptions
Bit Field Type Reset Description
3-1
ACTIV_BIR_DIR_C
TRL_GPIO_61
R/W 0h
Control to indicate whether the GPIO_61 needs dynamic
ouptu t enabling.
0 to 3 --> Static direction
4 --> Use the IO for 3 pin SPI B2 SDIO.
5 --> Use the IO for 4 pin SPI B2 SDO
6 --> Use the IO for 3 pin SPI B1 SDIO.
7 --> use the IO for 4 pin SPI B1 SDO.
0-0 reserved R/W 0h
2.16.365 Register 4F8h (offset = 4F8h) [reset = 1h]
Figure 2-2628. Register 4F8h
7 6 5 4 3 2 1 0
reserved reserved BUF_DIR_CTRL_GPIO_62
R/W-0h R/W-0h R/W-1h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2644. Register 4F8 Field Descriptions
Bit Field Type Reset Description
7-5 reserved R/W 0h
4-2 reserved R/W 0h
1-0
BUF_DIR_CTRL_G
PIO_62
R/W 1h
Controls the direction of GPIO
0 both input and output are not selected.. can be used for
analog
1 input mode
2 output mode
3 shouldnt be used
