Serial Interface Register Maps
Table 2-3010. Register 181A Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_FB_
NCO_SW
R 0h read only register for function intpi_fb_nco_sw
2.16.732 Register 181Bh (offset = 181Bh) [reset = 0h]
Figure 2-2995. Register 181Bh
7 6 5 4 3 2 1 0
READ_INTPI_
RXA_ALC_INP
UT_3_B0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3011. Register 181B Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXA
_ALC_INPUT_3_B
0
R 0h read only register for function intpi_rxa_alc_input_3_b0
2.16.733 Register 181Ch (offset = 181Ch) [reset = 0h]
Figure 2-2996. Register 181Ch
7 6 5 4 3 2 1 0
READ_INTPI_
RXB_ALC_INP
UT_3_B0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3012. Register 181C Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXB
_ALC_INPUT_3_B
0
R 0h read only register for function intpi_rxb_alc_input_3_b0
2.16.734 Register 181Dh (offset = 181Dh) [reset = 0h]
Figure 2-2997. Register 181Dh
7 6 5 4 3 2 1 0
READ_INTPI_
RXC_ALC_INP
UT_3_B0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3013. Register 181D Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXC
_ALC_INPUT_3_B
0
R 0h read only register for function intpi_rxc_alc_input_3_b0
