www.ti.com DAC JESD Register Map
263
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
Table 2-236. Register 22 Field Descriptions (continued)
Bit Field Type Reset Description
5-0
LINK0_JESD_MOD
E
R/W 5h
Defines the LMFSHd mode for path for lanes[0:1]/[4:5] path
0 : 24410
1 : 14810
2 : 14610
3 : 24610
4 : 1-4-12-1-0
5 : 44210
6 : 12820
7 : 48410
8 : 28810
9 : 28610
10 : 48610
11 : 2-8-12-1-0
12 : 24820
13 : 48310
14 : 24310
15 : 44310
16 : 1-8-12-1-0
17 : 1-8-16-1-0
18 : 42111
19 : 42220
20 : NA
21 : NA
22 : 22210
23 : 12310
24 : 22310
25 : 12410
26 : 12610
27 : 48820
28 : 4-16-8-1-0
29 : 2-16-12-1-0
30 : 4-16-12-1-0
31 : 2-16-16-1-0
32 : 1-16-24-1-0
33 : 1-8-24-1-0
34 : 2-16-24-1-0
35 : 12620
36 : 24620
37 : 48620
38 : 22840
39 : 44840
40 : NA
41 : NA
42 : NA
43 : NA
44 : NA
45 : NA
46 : NA
47 : NA
48 : NA
2.4.4 Register 23h (offset = 23h) [reset = 45h]
Figure 2-233. Register 23h
7 6 5 4 3 2 1 0
LINK1_JESD_SAMPLE_MODE LINK1_JESD_MODE
R/W-1h R/W-5h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
