www.ti.com IO Wrap Register Map
1241
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
2.16.735 Register 181Eh (offset = 181Eh) [reset = 0h]
Figure 2-2998. Register 181Eh
7 6 5 4 3 2 1 0
READ_INTPI_
RXD_ALC_INP
UT_3_B0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3014. Register 181E Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_RXD
_ALC_INPUT_3_B
0
R 0h read only register for function intpi_rxd_alc_input_3_b0
2.16.736 Register 181Fh (offset = 181Fh) [reset = 0h]
Figure 2-2999. Register 181Fh
7 6 5 4 3 2 1 0
READ_INTPI_I
NTERRUPT0_
TOPMCU
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3015. Register 181F Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_INTE
RRUPT0_TOPMC
U
R 0h read only register for function intpi_interrupt0_topcm4
2.16.737 Register 1820h (offset = 1820h) [reset = 0h]
Figure 2-3000. Register 1820h
7 6 5 4 3 2 1 0
READ_INTPI_I
NTERRUPT1_
TOPMCU
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-3016. Register 1820 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_INTE
RRUPT1_TOPMC
U
R 0h read only register for function intpi_interrupt1_topcm4
