List of Macros
89
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Macro
Table 1-22.
Macro Channel Frequency Resolution
Opcode 0x2F
Operand Offset Length Value Functionality Results
1 0x00 1 Mode Frequency
Resolution Mode
0 → 1 kHz
resolution
1 → 32-bit
resolution mode
>1 → RESERVED
Memory Not used
1.2.1.11.1 Error Reporting
Table 1-23 lists the error conditions associated with this macro.
Table 1-23.
Error Status Registers Interpretation
Error Code 1 (16-bit) Bit[0]: ‘1’ → Invalid Frequency Resolution argument.
Error Code 2 (32-bit) Not Used
1.2.1.12 TX Channel Frequency Set
This Macro specifies the channel frequencies (or carrier frequencies) for the TX channels. It allows
configuration of up to two frequencies for each band. These are designated as NCO 1 and NCO 2 (NCO:
Numerically controlled Oscillator). The unit of the frequency value specified in the macro is determined by
the Channel Frequency Resolution macro; hence the resolution supported by this interface is either 1000
Hz or TX-DAC-RATE/2
32
. To specify a frequency in the first Nyquist zone, the frequency value should be
lower than TX-DAC-RATE/2. To specify a frequency in the second Nyquist zone, the frequency value
should fall between TX-DAC-RATE/2 and TX-DAC-RATE. Even so, the Nyquist Zone of the target TX
channel-frequency should be specified through the TX Nyquist Zone Configuration Macro.
Table 1-24.
Macro TX Channel Frequency set
Opcode 0x30
Operand Offset Length Value Functionality Results
1 0x00 1 Validity TX Channel
Frequency validity
Bit 0: 1 → Channel
Frequency value is
applicable to 1TX
Bit 1: 1 → Channel
Frequency value is
applicable to 2TX
Bit 2: 1 → Channel
Frequency value is
applicable to 3TX
Bit 3: 1 → Channel
Frequency value is
applicable to 4TX
Bits 7:4 →
RESERVED
