www.ti.com
RX Top Register Map
833
SBAU337May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
Table 2-1838. Register 5B1 Field Descriptions
Bit Field Type Reset Description
1-0
RX_AGC_BAND1_
LNA_PHASE26[9:8
]
R/W 0h
LNA Phase for Band1 for temp index 26 in case of External
LNA Control , Phase for DVGA Index 58 in case of External
DVGA control
2.13.414 Register 5B2h (offset = 5B2h) [reset = 0h]
Figure 2-1826. Register 5B2h
7 6 5 4 3 2 1 0
RX_AGC_BAND1_LNA_PHASE27[7:0]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1839. Register 5B2 Field Descriptions
Bit Field Type Reset Description
7-0
RX_AGC_BAND1_
LNA_PHASE27[7:0
]
R/W 0h
LNA Phase for Band1 for temp index 27 in case of External
LNA Control , Phase for DVGA Index 59 in case of External
DVGA control
2.13.415 Register 5B3h (offset = 5B3h) [reset = 0h]
Figure 2-1827. Register 5B3h
7 6 5 4 3 2 1 0
RX_AGC_BAND1_LNA_PHASE
27[9:8]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1840. Register 5B3 Field Descriptions
Bit Field Type Reset Description
1-0
RX_AGC_BAND1_
LNA_PHASE27[9:8
]
R/W 0h
LNA Phase for Band1 for temp index 27 in case of External
LNA Control , Phase for DVGA Index 59 in case of External
DVGA control
2.13.416 Register 5B4h (offset = 5B4h) [reset = 0h]
Figure 2-1828. Register 5B4h
7 6 5 4 3 2 1 0
RX_AGC_BAND1_LNA_PHASE28[7:0]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1841. Register 5B4 Field Descriptions
Bit Field Type Reset Description
7-0
RX_AGC_BAND1_
LNA_PHASE28[7:0
]
R/W 0h
LNA Phase for Band1 for temp index 28 in case of External
LNA Control , Phase for DVGA Index 60 in case of External
DVGA control
