Serial Interface Register Maps
Table 2-2923. Register 140D Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_RX
C_PKDET_2
R 0h read only register for function intpo_rxc_pkdet_2
2.16.645 Register 140Eh (offset = 140Eh) [reset = 0h]
Figure 2-2908. Register 140Eh
7 6 5 4 3 2 1 0
READ_INTPO_
RXC_PKDET_3
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2924. Register 140E Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_RX
C_PKDET_3
R 0h read only register for function intpo_rxc_pkdet_3
2.16.646 Register 140Fh (offset = 140Fh) [reset = 0h]
Figure 2-2909. Register 140Fh
7 6 5 4 3 2 1 0
READ_INTPO_
RXD_PKDET_0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2925. Register 140F Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_RX
D_PKDET_0
R 0h read only register for function intpo_rxd_pkdet_0
2.16.647 Register 1410h (offset = 1410h) [reset = 0h]
Figure 2-2910. Register 1410h
7 6 5 4 3 2 1 0
READ_INTPO_
RXD_PKDET_1
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2926. Register 1410 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_RX
D_PKDET_1
R 0h read only register for function intpo_rxd_pkdet_1
