2.16.700 Register 17F7h (offset = 17F7h) [reset = 0h]
Figure 2-2963. Register 17F7h
7 6 5 4 3 2 1 0
READ_INTPI_S
PIB1_CLK
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2979. Register 17F7 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_SPIB
1_CLK
R 0h read only register for function intpi_spib1_clk
2.16.701 Register 17F8h (offset = 17F8h) [reset = 0h]
Figure 2-2964. Register 17F8h
7 6 5 4 3 2 1 0
READ_INTPI_A
DC_SYNC_N_
AB_0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2980. Register 17F8 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_ADC
_SYNC_N_AB_0
R 0h read only register for function intpi_adc_sync_n_ab_0
2.16.702 Register 17F9h (offset = 17F9h) [reset = 0h]
Figure 2-2965. Register 17F9h
7 6 5 4 3 2 1 0
READ_INTPI_A
DC_SYNC_N_
AB_1
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2981. Register 17F9 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPI_ADC
_SYNC_N_AB_1
R 0h read only register for function intpi_adc_sync_n_ab_1
