Serial Interface Register Maps
Table 2-242. Register 28 Field Descriptions
Bit Field Type Reset Description
7-7
MAPPER_SYNC_F
IFO_TX4_MODE_
OVR
R/W 0h UNUSED
6-6
MAPPER_SYNC_F
IFO_TX3_MODE_
OVR
R/W 0h UNUSED
5-5
MAPPER_SYNC_F
IFO_TX2_MODE_
OVR
R/W 0h
Enable mapper sync-fifo mode override through this register.
To be used along with mapper_sync_fifo_tx2_mode_val.
4-4
MAPPER_SYNC_F
IFO_TX1_MODE_
OVR
R/W 0h
Enable mapper sync-fifo mode override through this register.
To be used along with mapper_sync_fifo_tx1_mode_val.
3-3
MAPPER_SYNC_F
IFO_TX4_OFFSET
_OVR
R/W 0h
Enable mapper sync-fifo offset override through this register.
To be used along with mapper_sync_fifo_tx4_offset_val.
2-2
MAPPER_SYNC_F
IFO_TX3_OFFSET
_OVR
R/W 0h
Enable mapper sync-fifo offset override through this register.
To be used along with mapper_sync_fifo_tx3_offset_val.
1-1
MAPPER_SYNC_F
IFO_TX2_OFFSET
_OVR
R/W 0h
Enable mapper sync-fifo offset override through this register.
To be used along with mapper_sync_fifo_tx2_offset_val.
0-0
MAPPER_SYNC_F
IFO_TX1_OFFSET
_OVR
R/W 0h
Enable mapper sync-fifo offset override through this register.
To be used along with mapper_sync_fifo_tx1_offset_val.
2.4.10 Register 29h (offset = 29h) [reset = 88h]
Figure 2-239. Register 29h
7 6 5 4 3 2 1 0
MAPPER_SYNC_FIFO_TX2_OFFSET_VAL MAPPER_SYNC_FIFO_TX1_OFFSET_VAL
R/W-8h R/W-8h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-243. Register 29 Field Descriptions
Bit Field Type Reset Description
7-4
MAPPER_SYNC_F
IFO_TX2_OFFSET
_VAL
R/W 8h
set mapper sync-fifo offset through this register.To be used
along with mapper_sync_fifo_tx2_offset_ovr.
3-0
MAPPER_SYNC_F
IFO_TX1_OFFSET
_VAL
R/W 8h
set mapper sync-fifo offset through this register.To be used
along with mapper_sync_fifo_tx1_offset_ovr.
2.4.11 Register 2Ah (offset = 2Ah) [reset = Ah]
Figure 2-240. Register 2Ah
7 6 5 4 3 2 1 0
MAPPER_SYNC_FIFO_TX4_OF
FSET_VAL
MAPPER_SYNC_FIFO_TX3_OF
FSET_VAL
R/W-2h R/W-2h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
