Serial Interface Register Maps
Table 2-2916. Register 1406 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_RX
A_PKDET_3
R 0h read only register for function intpo_rxa_pkdet_3
2.16.638 Register 1407h (offset = 1407h) [reset = 0h]
Figure 2-2901. Register 1407h
7 6 5 4 3 2 1 0
READ_INTPO_
RXB_PKDET_0
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2917. Register 1407 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_RX
B_PKDET_0
R 0h read only register for function intpo_rxb_pkdet_0
2.16.639 Register 1408h (offset = 1408h) [reset = 0h]
Figure 2-2902. Register 1408h
7 6 5 4 3 2 1 0
READ_INTPO_
RXB_PKDET_1
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2918. Register 1408 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_RX
B_PKDET_1
R 0h read only register for function intpo_rxb_pkdet_1
2.16.640 Register 1409h (offset = 1409h) [reset = 0h]
Figure 2-2903. Register 1409h
7 6 5 4 3 2 1 0
READ_INTPO_
RXB_PKDET_2
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-2919. Register 1409 Field Descriptions
Bit Field Type Reset Description
0-0
READ_INTPO_RX
B_PKDET_2
R 0h read only register for function intpo_rxb_pkdet_2
