Serial Interface Register Maps
2.5.138 Register CAh (offset = CAh) [reset = 1h]
Figure 2-634. Register CAh
7 6 5 4 3 2 1 0
0 0 0 0 0 0 0 SCR_64B_EN
R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h R/W-1h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-639. Register CA Field Descriptions
Bit Field Type Reset Description
7-1 0 R/W 0h Must read or write 0
0-0 SCR_64B_EN R/W 1h
Used in JESD-C
To enable/disable 64 bit scrambler
(1+x^39+x^58)
1 : 64b scr enabled
0 : 64b scr disabled
2.5.139 Register CBh (offset = CBh) [reset = 0h]
Figure 2-635. Register CBh
7 6 5 4 3 2 1 0
0 0 0 0 0 0 reserved SCR_64B_BIT_
SWAP_DISABL
E
R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-640. Register CB Field Descriptions
Bit Field Type Reset Description
7-2 0 R/W 0h Must read or write 0
1-1 reserved R/W 0h
0-0
SCR_64B_BIT_SW
AP_DISABLE
R/W 0h
In JESD-C
By default, bit order is NOT reversed
When 1, bit order within each byte is reversed, before going to
64b scrambler
2.5.140 Register CCh (offset = CCh) [reset = 0h]
Figure 2-636. Register CCh
7 6 5 4 3 2 1 0
JESDC_CMD[7:0]
R/W-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-641. Register CC Field Descriptions
Bit Field Type Reset Description
7-0 JESDC_CMD[7:0] R/W 0h
For JESD-C
6 bits corresponding to 6 command bits used in CRC and FEC
encoding.
All 18 bits are used in CMD encoding is used
