Table 2-1409. Register 597 Field Descriptions
Bit Field Type Reset Description
7-0
TX_PAP_DYN_OU
T_PULSE_EXTEN
SION[15:8]
R/W 2Ch
Pulse extension for the Dynamic version of PAP alarm going
from TxA to GPIO. Any value from 0 to 2^16-1 can be
programmed and the extension is terms of Tx digital clock
divided by 4.
2.12.195 Register 5A0h (offset = 5A0h) [reset = 0h]
Figure 2-1398. Register 5A0h
7 6 5 4 3 2 1 0
TX_IP_PAP_MA_PWR_AVG_BAND0[7:0]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1410. Register 5A0 Field Descriptions
Bit Field Type Reset Description
7-0
TX_IP_PAP_MA_P
WR_AVG_BAND0[
7:0]
R 0h
Input PAP band0 power detection module average power
output. The linear scale value is interpreted as
read_value/2^16
2.12.196 Register 5A1h (offset = 5A1h) [reset = 0h]
Figure 2-1399. Register 5A1h
7 6 5 4 3 2 1 0
TX_IP_PAP_MA_PWR_AVG_BAND0[15:8]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1411. Register 5A1 Field Descriptions
Bit Field Type Reset Description
7-0
TX_IP_PAP_MA_P
WR_AVG_BAND0[
15:8]
R 0h
Input PAP band0 power detection module average power
output. The linear scale value is interpreted as
read_value/2^16
2.12.197 Register 5A2h (offset = 5A2h) [reset = 0h]
Figure 2-1400. Register 5A2h
7 6 5 4 3 2 1 0
TX_IP_PAP_M
A_PWR_AVG_
BAND0[16]
R-0h
LEGEND: R/W = Read/Write; W = Write only; -n = value after reset
Table 2-1412. Register 5A2 Field Descriptions
Bit Field Type Reset Description
0-0
TX_IP_PAP_MA_P
WR_AVG_BAND0[
16]
R 0h
Input PAP band0 power detection module average power
output. The linear scale value is interpreted as
read_value/2^16
