Macro
Table 1-47. (continued)
Macro RX DSA Gain-Phase Factory Calibration
2 0x01 1 Calib. Module Calibration Module
0 → RESERVED
1 → RX DSA
Calibration
>1 → RESERVED
This operand should
be provided for all
the calibration
commands.
3 0x02 1 RESERVED
Write 0 here
4 0x03 1 RESERVED
Write 0 here
This is used only
during ‘Start’
Calibration
Command
5 0x04 1 Channel Selection Chain Selection:
Bit 0: 1 → Do 1RX
Calibration
Bit 1: 1 → Do 2RX
Calibration
Bit 2: 1 → Do 3RX
Calibration
Bit 3: 1 → Do 4RX
Calibration
Bits 7:4 →
RESERVED
Used during
‘Continue’ and
‘Perform Clock
Configuration’
calibration
commands.
6 0x05 1 Band Selection Band Selection for
Rx
Bit [1:0]: Bands to
be enabled for 1RX.
LSB is for Band1
and MSB is for
Band2
Bits[3:2]: Bands to
be enabled for 2RX.
Bits[5:4]: Bands to
be enabled for 3RX.
Bits[7:6]: Bands to
be enabled for 4RX.
Used only during
‘continue’ calibration
command
7 0x06 1 RESERVED
Write 0 here
8 0x07 1 RESERVED
Write 0 here
9 0x08 1 Stop DSA Attn. Stop DSA Attn
Maximum DSA
attenuation (in dB)
till which the RX-
DSA gain-phase
calibration should
be done for. 0 ≤
Stop-DSA-Attn ≤ 25
10 0x09 1 RESERVED.
Write 0x63 here
11 0x0A 1 RESERVED
Write 0 here
12 0x0B 1 RESERVED
Write 0 here
13 0x0C 1 RESERVED
Write 0 here
14 0x0D 1 RESERVED
Write 0 here
15 0x0E 1 RESERVED
Write 0 here
