List of Macros
www.ti.com
122
SBAU337May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Macro
Table 1-70. (continued)
Macro AGC Dual LNA Time Crossings
1 0x00 1 RX Channel Select Bit 0: 1 Value
specified in
subsequent
operands is valid for
1RX.
Bit 1: 1 Value
specified in
subsequent
operands is valid for
2RX.
Bit 2: 1 Value
specified in
subsequent
operands is valid for
3RX.
Bit 3: 1 Value
specified in
subsequent
operands is valid for
4RX.
Bit 4 RESERVED
Bit 5 RESERVED
3 0x02 1 Absolute/Relative
time crossings for
band detector in
decay mode.
0: Absolute
1: Relative
If time crossings are specified as Absolute Number
4 0x03 3 Number of samples
at F
BAND
(Band
Detector Clock
Rate) for Band
detector 1 to
declare decay for
Band 1
5 0x06 3 Number of samples
at F
BAND
(Band
Detector Clock
Rate) for Band
detector 2 to
declare decay for
Band 2
If time crossings are specified as Relative Number
4 0x03 2 Fraction of samples
crossing signal
threshold in given
time constant for
Band detector 1 to
declare decay for
Band 1.
5 0x03 2 Fraction of samples
crossing signal
threshold in given
time constant for
Band detector 2 to
declare decay for
Band 2.
If Band Detector Bandwidth Selection is set to output bandwidth then F
BAND
= Output Rate.
If Band Detector Bandwidth Selection is set to higher bandwidth then use the table below.
