www.ti.com ADC JESD Register Map
383
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
Table 2-516. Register 34 Field Descriptions (continued)
Bit Field Type Reset Description
5-0 RX1_JESD_MODE R/W 0h
S=1
MODE_1S_24410_IQ = 0
MODE_1S_14810_IQ = 1
MODE_1S_14610_IQ = 2
MODE_1S_24610_IQ = 3
MODE_1S_141210_IQ = 4
MODE_1S_44210_IQ = 5
MODE_1S_28810_IQ = 6
MODE_1S_28610_IQ = 7
MODE_1S_48610_IQ = 8
MODE_1S_42111_IQ = 9
MODE_1S_48410_IQ = 10
MODE_1S_12310_IQ = 11
MODE_1S_22210_IQ = 12
MODE_1S_48310_IQ = 13
MODE_1S_24310_IQ = 14
MODE_1S_44310_IQ = 15
MODE_1S_181210_IQ = 16
MODE_1S_281210_IQ = 17
MODE_1S_42220_IQ = 19
MODE_1S_181610_IQ = 20
MODE_1S_182410_IQ = 21
MODE_1S_12610_IQ = 22
MODE_1S_12410_IQ = 23
MODE_1S_141610_IQ = 24
MODE_1S_183210_IQ = 25
MODE_1S_1163210_IQ = 26
MODE_1S_1162410_IQ = 27
MODE_1S_TOR_22210 = 50
S=2
MODE_2S_24820_IQ = 0
MODE_2S_12810_IQ = 1
MODE_2S_24620_IQ = 2
MODE_2S_44620_IQ = 3
MODE_2S_44420_IQ = 4
MODE_2S_22320_IQ = 5
MODE_2S_142420_IQ = 6
MODE_2S_41240_IQ = 7
MODE_2S_41121_IQ = 8
MODE_2S_44210_IQ = 9
MODE_2S_42220_IQ = 10
MODE_2S_14810_IQ = 11
MODE_2S_121620_IQ_DUP = 12
MODE_2S_241220_IQ = 13
MODE_2S_141610_IQ = 14
MODE_2S_42320_IQ = 15
MODE_2S_24410_IQ = 16
MODE_2S_12610_IQ = 17
MODE_2S_12410_IQ = 18
MODE_2S_12310_IQ = 19
MODE_2S_121620_IQ = 20
MODE_2S_121220_IQ = 21
MODE_2S_12820_IQ = 22
MODE_2S_12620_IQ = 23
MODE_2S_22210_IQ = 24
MODE_2S_22310_IQ = 25
MODE_2S_32411_IQ_DUP = 26
MODE_2S_32211_IQ = 27
MODE_2S_12810_IQ_DUP = 28
MODE_2S_121210_IQ_DUP = 29
MODE_2S_22420_IQ = 30
MODE_2S_22620_IQ = 31
MODE_2S_122420_IQ_DUP = 32
MODE_2S_121640_IQ = 33
MODE_2S_22840_IQ = 34
MODE_2S_122440_IQ = 35
MODE_2S_321230_IQ_DUP = 36
MODE_2S_32830_IQ_DUP = 37
MODE_2S_32630_IQ = 38
