Serial Interface Register Maps
Table 2-939. Macro Register Map (continued)
ADDRESS (Hex) D7 D6 D5 D4 D3 D2 D1 D0
D5h MACRO_OPERAND_REG13[15:8]
D6h MACRO_OPERAND_REG13[23:16]
D7h MACRO_OPERAND_REG13[31:24]
D8h MACRO_OPERAND_REG14[7:0]
D9h MACRO_OPERAND_REG14[15:8]
DAh MACRO_OPERAND_REG14[23:16]
DBh MACRO_OPERAND_REG14[31:24]
DCh MACRO_OPERAND_REG15[7:0]
DDh MACRO_OPERAND_REG15[15:8]
DEh MACRO_OPERAND_REG15[23:16]
DFh MACRO_OPERAND_REG15[31:24]
E0h MACRO_OPERAND_REG16[7:0]
E1h MACRO_OPERAND_REG16[15:8]
E2h MACRO_OPERAND_REG16[23:16]
E3h MACRO_OPERAND_REG16[31:24]
E4h MACRO_OPERAND_REG17[7:0]
E5h MACRO_OPERAND_REG17[15:8]
E6h MACRO_OPERAND_REG17[23:16]
E7h MACRO_OPERAND_REG17[31:24]
E8h MACRO_OPERAND_REG18[7:0]
E9h MACRO_OPERAND_REG18[15:8]
EAh MACRO_OPERAND_REG18[23:16]
EBh MACRO_OPERAND_REG18[31:24]
ECh MACRO_OPERAND_REG19[7:0]
EDh MACRO_OPERAND_REG19[15:8]
EEh MACRO_OPERAND_REG19[23:16]
EFh MACRO_OPERAND_REG19[31:24]
F0h
MACRO_ERRO
R_IN_EXECUTI
ON
MACRO_ERRO
R_IN_OPERAN
D
MACRO_ERRO
R_OPCODE_NO
T_ALLOWED
MACRO_ERRO
R_IN_OPCODE
MACRO_ERRO
R
MACRO_DONE MACRO_ACK MACRO_READY
F1h MACRO_ERROR_OPCODE
F2h MACRO_ERROR_EXTENDED_CODE[7:0]
F3h MACRO_ERROR_EXTENDED_CODE[15:8]
F4h MACRO_ERROR_EXTENDED_CODE_2[7:0]
F5h MACRO_ERROR_EXTENDED_CODE_2[15:8]
F6h MACRO_ERROR_EXTENDED_CODE_2[23:16]
F7h MACRO_ERROR_EXTENDED_CODE_2[31:24]
F8h MACRO_RESULT_REG0[7:0]
F9h MACRO_RESULT_REG0[15:8]
FAh MACRO_RESULT_REG0[23:16]
FBh MACRO_RESULT_REG0[31:24]
FCh MACRO_RESULT_REG1[7:0]
FDh MACRO_RESULT_REG1[15:8]
FEh MACRO_RESULT_REG1[23:16]
FFh MACRO_RESULT_REG1[31:24]
100h MACRO_RESULT_REG2[7:0]
101h MACRO_RESULT_REG2[15:8]
102h MACRO_RESULT_REG2[23:16]
103h MACRO_RESULT_REG2[31:24]
104h MACRO_RESULT_REG3[7:0]
105h MACRO_RESULT_REG3[15:8]
106h MACRO_RESULT_REG3[23:16]
107h MACRO_RESULT_REG3[31:24]
108h MACRO_RESULT_REG4[7:0]
109h MACRO_RESULT_REG4[15:8]
10Ah MACRO_RESULT_REG4[23:16]
10Bh MACRO_RESULT_REG4[31:24]
