RX Top Register Map
www.ti.com
702
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
Table 2-1425. rx_top_AB Register Map (continued)
ADDRESS (Hex) D7 D6 D5 D4 D3 D2 D1 D0
1E3h RX_DDC_BAND1_NCO1_PHASE_OFFSET[15:8]
200h RX_DDC_BAND1_NCO0_FMULT[7:0]
201h RX_DDC_BAND1_NCO0_FMULT[15:8]
202h RX_DDC_BAND1_NCO0_FMULT[21:16]
204h RX_DDC_BAND1_NCO1_FMULT[7:0]
205h RX_DDC_BAND1_NCO1_FMULT[15:8]
206h RX_DDC_BAND1_NCO1_FMULT[21:16]
240h RX_DDC_BAND1_NCO0_FRAC_FCW_NUM[7:0]
241h RX_DDC_BAND1_NCO0_FRAC_FCW_NUM[15:8]
242h RX_DDC_BAND1_NCO0_FRAC_FCW_DEN[7:0]
243h RX_DDC_BAND1_NCO0_FRAC_FCW_DEN[15:8]
244h RX_DDC_BAND1_NCO1_FRAC_FCW_NUM[7:0]
245h RX_DDC_BAND1_NCO1_FRAC_FCW_NUM[15:8]
246h RX_DDC_BAND1_NCO1_FRAC_FCW_DEN[7:0]
247h RX_DDC_BAND1_NCO1_FRAC_FCW_DEN[15:8]
288h RX_DDC_BAND1_DIG_GAIN_INDEX
400h
RX_AGC_DIG_B
AND1_DET_EN
RX_AGC_DIG_B
AND0_DET_EN
RX_AGC_PWR_
DECAY_EN
RX_AGC_PWR_
ATTACK_EN
RX_AGC_SMAL
L_STEP_DECAY
_EN
RX_AGC_BIG_S
TEP_DECAY_E
N
RX_AGC_SMAL
L_STEP_ATTAC
K_EN
RX_AGC_BIG_S
TEP_ATTACK_E
N
401h
RX_AGC_LNAR
F_DETECT_MO
DE
RX_AGC_LNA_
RF_ATTACK_E
N
402h
RX_AGC_EXT_
DVGA_CNTRL_
EN
RX_AGC_EXT_L
NA_CNTL_EN
404h
RX_AGC_BAND
_PK_DET_EN
RX_AGC_PWR_
DECAY_DET_E
N
RX_AGC_PWR_
ATTACK_DET_E
N
RX_AGC_SMAL
L_STEP_DECAY
_DET_EN
RX_AGC_BIG_S
TEP_DECAY_D
ET_EN
RX_AGC_SMAL
L_STEP_ATTAC
K_DET_EN
RX_AGC_BIG_S
TEP_ATTACK_D
ET_EN
405h
RX_AGC_LNA_
RF_ATTACK_D
ET_EN
408h RX_AGC_BIG_STEP_ATTACK_STEP_SIZE
409h RX_AGC_SMALL_STEP_ATTACK_STEP_SIZE
40Ah RX_AGC_BIG_STEP_DECAY_STEP_SIZE
40Bh RX_AGC_SMALL_STEP_DECAY_STEP_SIZE
40Ch RX_AGC_PWR_ATTACK_STEP_SIZE
40Dh RX_AGC_PWR_DECAY_STEP_SIZE
410h RX_AGC_LNARF_ATTACK_STEP_SIZE
414h RX_AGC_BIG_STEP_ATTACK_WIN_LEN[7:0]
415h RX_AGC_BIG_STEP_ATTACK_WIN_LEN[15:8]
416h RX_AGC_BIG_STEP_ATTACK_WIN_LEN[23:16]
418h RX_AGC_SMALL_STEP_ATTACK_WIN_LEN[7:0]
419h RX_AGC_SMALL_STEP_ATTACK_WIN_LEN[15:8]
41Ah RX_AGC_SMALL_STEP_ATTACK_WIN_LEN[23:16]
41Ch RX_AGC_BIG_STEP_DECAY_WIN_LEN[7:0]
41Dh RX_AGC_BIG_STEP_DECAY_WIN_LEN[15:8]
41Eh RX_AGC_BIG_STEP_DECAY_WIN_LEN[23:16]
420h RX_AGC_SMALL_STEP_DECAY_WIN_LEN[7:0]
421h RX_AGC_SMALL_STEP_DECAY_WIN_LEN[15:8]
422h RX_AGC_SMALL_STEP_DECAY_WIN_LEN[23:16]
424h RX_AGC_PWR_DET_ATTACK_WIN_LEN
425h RX_AGC_PWRDET_DECAY_WIN_LEN
428h RX_AGC_LNA_RF_DET_ATTACK_WIN_LEN[7:0]
429h RX_AGC_LNA_RF_DET_ATTACK_WIN_LEN[15:8]
42Ah RX_AGC_LNA_RF_DET_ATTACK_WIN_LEN[23:16]
42Ch RX_AGC_BIG_STEP_ATTACK_SIG_TH[7:0]
42Dh RX_AGC_BIG_STEP_ATTACK_SIG_TH[11:8]
430h RX_AGC_SMALL_STEP_ATTACK_SIG_TH[7:0]
431h RX_AGC_SMALL_STEP_ATTACK_SIG_TH[11:8]
434h RX_AGC_BIG_STEP_DECAY_SIG_TH[7:0]
