www.ti.com SLEEP MODE CONTROL
133
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Macro
Table 1-82. (continued)
Macro Sleep Mode Configuration
1 0x00 1 RX Channel Select Bit 0: 1 → 1RX will
go to sleep when
sleep is triggered.
Bit 1: 1 → 2RX will
go to sleep when
sleep is triggered.
Bit 2: 1 → 3RX will
go to sleep when
sleep is triggered.
Bit 3: 1 → 4RX will
go to sleep when
sleep is triggered.
2 0x01 1 RX Sleep Mode Bit 0:
0 → 1RX will go to
light sleep when
sleep is triggered
1 → 1RX will go to
deep sleep when
sleep is triggered
Bit 1:
0 → 2RX will go to
light sleep when
sleep is triggered
1 → 2RX will go to
deep sleep when
sleep is triggered Bit
2:
0 → 3RX will go to
light sleep when
sleep is triggered
1 → 3RX will go to
deep sleep when
sleep is triggered Bit
3:
0 → 4RX will go to
light sleep when
sleep is triggered
1 → 4RX will go to
deep sleep when
sleep is triggered
3 0x02 1 FB Channel Select Bit 0: 1 → 1FB will
go to sleep when
sleep is triggered
Bit 1: 1 → 2FB will
go to sleep when
sleep is triggered
4 0x03 1 FB Sleep Mode Bit 0:
0 → 1FB will go to
light sleep when
sleep is triggered
1 → 1FB will go to
deep sleep when
sleep is triggered
Bit 1: 0 → 2FB will
go to light sleep
when sleep is
triggered
1 → 2FB will go to
deep sleep when
sleep is triggered
