SLEEP MODE CONTROL www.ti.com
134
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Macro
Table 1-82. (continued)
Macro Sleep Mode Configuration
5 0x04 1 TX Channel Select Bit 0: 1 → 1TX will
go to sleep when
sleep is triggered
Bit 1: 1 → 2TX will
go to sleep when
sleep is triggered
Bit 2: 1 → 3TX will
go to sleep when
sleep is triggered
Bit 3: 1 → 4TX will
go to sleep when
sleep is triggered
6 0x05 1 TX Sleep Mode Bit 0:
0 → 1TX will go to
light sleep when
sleep is triggered
1 → 1TX will go to
deep sleep when
sleep is triggered
Bit 1:
0 → 2TX will go to
light sleep when
sleep is triggered
1 → 2TX will go to
deep sleep when
sleep is triggered
Bit 2:
0 → 3TX will go to
light sleep when
sleep is triggered
1 → 3TX will go to
deep sleep when
sleep is triggered
Bit 3:
0 → 4TX will go to
light sleep when
sleep is triggered
1 → 4TX will go to
deep sleep when
sleep is triggered
7 0x06 1 RESERVED
Write 1 here
8 0x07 1 RESERVED
Write 0 here
9 0x08 1 RESERVED
Write 0 here
10 0x09 1 RESERVED
Write 0 here
11 0x0A 1 RESERVED
Write 0 here
12 0x0B 1 RESERVED
Write 0 here
13 0x0C 1 RESERVED
Write 0 here
14 0x0D 1 RESERVED
Write 0 here
15 0x0E 1 RESERVED
Write 0 here
16 0x0F 1 RESERVED
Write 0 here
17 0x10 1 RESERVED
Write 0 here
Memory Not used
