Serial Interface Register Maps
Table 2-233. DAC JESD Register Map (continued)
ADDRESS (Hex) D7 D6 D5 D4 D3 D2 D1 D0
F8h ALARMS_MASK[7:0]
F9h ALARMS_MASK[15:8]
FAh ALARMS_MASK[23:16]
FBh ALARMS_MASK[31:24]
FCh ALARMS_MASK[39:32]
FDh ALARMS_MASK[47:40]
FEh ALARMS_MASK[55:48]
FFh ALARMS_MASK[63:56]
100h ALARMS_CLEAR[7:0]
101h ALARMS_CLEAR[15:8]
102h ALARMS_CLEAR[23:16]
103h ALARMS_CLEAR[31:24]
104h ALARMS_CLEAR[39:32]
105h ALARMS_CLEAR[47:40]
106h ALARMS_CLEAR[55:48]
107h ALARMS_CLEAR[63:56]
108h ALARMS_TO_PAP_MASK[7:0]
109h ALARMS_TO_PAP_MASK[15:8]
10Ah ALARMS_TO_PAP_MASK[23:16]
10Bh ALARMS_TO_PAP_MASK[31:24]
10Ch ALARMS_TO_PAP_MASK[39:32]
10Dh ALARMS_TO_PAP_MASK[47:40]
10Eh ALARMS_TO_PAP_MASK[55:48]
10Fh ALARMS_TO_PAP_MASK[63:56]
110h ALARMS_TO_PAP_CLEAR[7:0]
111h ALARMS_TO_PAP_CLEAR[15:8]
112h ALARMS_TO_PAP_CLEAR[23:16]
113h ALARMS_TO_PAP_CLEAR[31:24]
114h ALARMS_TO_PAP_CLEAR[39:32]
115h ALARMS_TO_PAP_CLEAR[47:40]
116h ALARMS_TO_PAP_CLEAR[55:48]
117h ALARMS_TO_PAP_CLEAR[63:56]
118h ALARMS[7:0]
119h ALARMS[15:8]
11Ah ALARMS[23:16]
11Bh ALARMS[31:24]
11Ch ALARMS[39:32]
11Dh ALARMS[47:40]
11Eh ALARMS[55:48]
11Fh ALARMS[63:56]
120h ALARMS_TO_PAP[7:0]
121h ALARMS_TO_PAP[15:8]
122h ALARMS_TO_PAP[23:16]
123h ALARMS_TO_PAP[31:24]
124h ALARMS_TO_PAP[39:32]
125h ALARMS_TO_PAP[47:40]
126h ALARMS_TO_PAP[55:48]
127h ALARMS_TO_PAP[63:56]
128h
DIRECT_LANE3
_ERRORS_TO_
PAP_EN
DIRECT_LANE2
_ERRORS_TO_
PAP_EN
DIRECT_LANE1
_ERRORS_TO_
PAP_EN
DIRECT_LANE0
_ERRORS_TO_
PAP_EN
MASK_ALL_ALA
RMS_TO_PAP
CLEAR_ALL_AL
ARMS_TO_PAP
MASK_ALL_ALA
RMS
CLEAR_ALL_AL
ARMS
12Ah LANE_ERRORS_PULSE_EXPANSION_COUNT_LANE01
12Bh LANE_ERRORS_PULSE_EXPANSION_COUNT_LANE23
12Ch TXB_LANE_ALARMS_TO_PAP_EN TXA_LANE_ALARMS_TO_PAP_EN
12Dh TXD_LANE_ALARMS_TO_PAP_EN TXC_LANE_ALARMS_TO_PAP_EN
138h LINK0_SYNC_RELEASE_RBD_M1[7:0]
139h LINK0_SYNC_RELEASE_RBD_M1[15:8]
