Serial Interface Register Maps
Table 2-1425. rx_top_AB Register Map (continued)
ADDRESS (Hex) D7 D6 D5 D4 D3 D2 D1 D0
577h
RX_AGC_BAND0_LNA_PHASE29[9
:8]
578h RX_AGC_BAND0_LNA_PHASE30[7:0]
579h
RX_AGC_BAND0_LNA_PHASE30[9
:8]
57Ah RX_AGC_BAND0_LNA_PHASE31[7:0]
57Bh
RX_AGC_BAND0_LNA_PHASE31[9
:8]
57Ch RX_AGC_BAND1_LNA_PHASE0[7:0]
57Dh
RX_AGC_BAND1_LNA_PHASE0[9:
8]
57Eh RX_AGC_BAND1_LNA_PHASE1[7:0]
57Fh
RX_AGC_BAND1_LNA_PHASE1[9:
8]
580h RX_AGC_BAND1_LNA_PHASE2[7:0]
581h
RX_AGC_BAND1_LNA_PHASE2[9:
8]
582h RX_AGC_BAND1_LNA_PHASE3[7:0]
583h
RX_AGC_BAND1_LNA_PHASE3[9:
8]
584h RX_AGC_BAND1_LNA_PHASE4[7:0]
585h
RX_AGC_BAND1_LNA_PHASE4[9:
8]
586h RX_AGC_BAND1_LNA_PHASE5[7:0]
587h
RX_AGC_BAND1_LNA_PHASE5[9:
8]
588h RX_AGC_BAND1_LNA_PHASE6[7:0]
589h
RX_AGC_BAND1_LNA_PHASE6[9:
8]
58Ah RX_AGC_BAND1_LNA_PHASE7[7:0]
58Bh
RX_AGC_BAND1_LNA_PHASE7[9:
8]
58Ch RX_AGC_BAND1_LNA_PHASE8[7:0]
58Dh
RX_AGC_BAND1_LNA_PHASE8[9:
8]
58Eh RX_AGC_BAND1_LNA_PHASE9[7:0]
58Fh
RX_AGC_BAND1_LNA_PHASE9[9:
8]
590h RX_AGC_BAND1_LNA_PHASE10[7:0]
591h
RX_AGC_BAND1_LNA_PHASE10[9
:8]
592h RX_AGC_BAND1_LNA_PHASE11[7:0]
593h
RX_AGC_BAND1_LNA_PHASE11[9
:8]
594h RX_AGC_BAND1_LNA_PHASE12[7:0]
595h
RX_AGC_BAND1_LNA_PHASE12[9
:8]
596h RX_AGC_BAND1_LNA_PHASE13[7:0]
597h
RX_AGC_BAND1_LNA_PHASE13[9
:8]
598h RX_AGC_BAND1_LNA_PHASE14[7:0]
599h
RX_AGC_BAND1_LNA_PHASE14[9
:8]
59Ah RX_AGC_BAND1_LNA_PHASE15[7:0]
59Bh
RX_AGC_BAND1_LNA_PHASE15[9
:8]
59Ch RX_AGC_BAND1_LNA_PHASE16[7:0]
59Dh
RX_AGC_BAND1_LNA_PHASE16[9
:8]
59Eh RX_AGC_BAND1_LNA_PHASE17[7:0]
59Fh
RX_AGC_BAND1_LNA_PHASE17[9
:8]
5A0h RX_AGC_BAND1_LNA_PHASE18[7:0]
