RX Top Register Map
709
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
Table 2-1425. rx_top_AB Register Map (continued)
ADDRESS (Hex) D7 D6 D5 D4 D3 D2 D1 D0
5A1h
RX_AGC_BAND1_LNA_PHASE18[9
:8]
5A2h RX_AGC_BAND1_LNA_PHASE19[7:0]
5A3h
RX_AGC_BAND1_LNA_PHASE19[9
:8]
5A4h RX_AGC_BAND1_LNA_PHASE20[7:0]
5A5h
RX_AGC_BAND1_LNA_PHASE20[9
:8]
5A6h RX_AGC_BAND1_LNA_PHASE21[7:0]
5A7h
RX_AGC_BAND1_LNA_PHASE21[9
:8]
5A8h RX_AGC_BAND1_LNA_PHASE22[7:0]
5A9h
RX_AGC_BAND1_LNA_PHASE22[9
:8]
5AAh RX_AGC_BAND1_LNA_PHASE23[7:0]
5ABh
RX_AGC_BAND1_LNA_PHASE23[9
:8]
5ACh RX_AGC_BAND1_LNA_PHASE24[7:0]
5ADh
RX_AGC_BAND1_LNA_PHASE24[9
:8]
5AEh RX_AGC_BAND1_LNA_PHASE25[7:0]
5AFh
RX_AGC_BAND1_LNA_PHASE25[9
:8]
5B0h RX_AGC_BAND1_LNA_PHASE26[7:0]
5B1h
RX_AGC_BAND1_LNA_PHASE26[9
:8]
5B2h RX_AGC_BAND1_LNA_PHASE27[7:0]
5B3h
RX_AGC_BAND1_LNA_PHASE27[9
:8]
5B4h RX_AGC_BAND1_LNA_PHASE28[7:0]
5B5h
RX_AGC_BAND1_LNA_PHASE28[9
:8]
5B6h RX_AGC_BAND1_LNA_PHASE29[7:0]
5B7h
RX_AGC_BAND1_LNA_PHASE29[9
:8]
5B8h RX_AGC_BAND1_LNA_PHASE30[7:0]
5B9h
RX_AGC_BAND1_LNA_PHASE30[9
:8]
5BAh RX_AGC_BAND1_LNA_PHASE31[7:0]
5BBh
RX_AGC_BAND1_LNA_PHASE31[9
:8]
5BCh
RX_AGC_ENAB
LE_GPIO_RESE
T_FEATURE
5C0h RX_AGC_CLK_DIV_FACTOR_DVGA_CTRL[7:0]
5C1h RX_AGC_CLK_DIV_FACTOR_DVGA_CTRL[10:8]
5C2h
RX_AGC_SWAP
_DVGA_SPI_OR
DER
5C4h
RX_AGC_UPDA
TE_DET_STATU
S
5D0h RX_AGC_AVG_PWR_DET_SEEN[7:0]
5D1h RX_AGC_AVG_PWR_DET_SEEN[15:8]
5D4h RX_AGC_DIG_DET_NUM_HITS_SEEN[7:0]
5D5h RX_AGC_DIG_DET_NUM_HITS_SEEN[15:8]
5D6h RX_AGC_DIG_DET_NUM_HITS_SEEN[23:16]
5DCh
RX_AGC_USE_
ALL_DETECTO
RS_AS_ATTAC
K
5E0h
RX_AGC_REST
ART_MAX_MIN
5E4h RX_AGC_MAX_ATTN_USED
5E5h RX_AGC_MIN_ATTN_USED
