Serial Interface Register Maps
Table 2-2279. io_wrap Register Map (continued)
ADDRESS (Hex) D7 D6 D5 D4 D3 D2 D1 D0
291h IBUF_ST_GPIO_36
292h ODRIV_DS_GPIO_36
294h PULL_CTRL_GPIO_37
295h IBUF_ST_GPIO_37
296h ODRIV_DS_GPIO_37
298h PULL_CTRL_GPIO_38
299h IBUF_ST_GPIO_38
29Ah ODRIV_DS_GPIO_38
29Ch PULL_CTRL_GPIO_39
29Dh IBUF_ST_GPIO_39
29Eh ODRIV_DS_GPIO_39
2A0h PULL_CTRL_GPIO_40
2A1h IBUF_ST_GPIO_40
2A2h ODRIV_DS_GPIO_40
2A4h PULL_CTRL_GPIO_41
2A5h IBUF_ST_GPIO_41
2A6h ODRIV_DS_GPIO_41
2A8h PULL_CTRL_GPIO_42
2A9h IBUF_ST_GPIO_42
2AAh ODRIV_DS_GPIO_42
2ACh PULL_CTRL_GPIO_43
2ADh IBUF_ST_GPIO_43
2AEh ODRIV_DS_GPIO_43
2B0h PULL_CTRL_GPIO_44
2B1h IBUF_ST_GPIO_44
2B2h ODRIV_DS_GPIO_44
2B4h PULL_CTRL_GPIO_45
2B5h IBUF_ST_GPIO_45
2B6h ODRIV_DS_GPIO_45
2B8h PULL_CTRL_GPIO_46
2B9h IBUF_ST_GPIO_46
2BAh ODRIV_DS_GPIO_46
2BCh PULL_CTRL_GPIO_47
2BDh IBUF_ST_GPIO_47
2BEh ODRIV_DS_GPIO_47
2C0h PULL_CTRL_GPIO_48
2C1h IBUF_ST_GPIO_48
2C2h ODRIV_DS_GPIO_48
2C4h PULL_CTRL_GPIO_49
2C5h IBUF_ST_GPIO_49
2C6h ODRIV_DS_GPIO_49
2C8h PULL_CTRL_GPIO_50
2C9h IBUF_ST_GPIO_50
2CAh ODRIV_DS_GPIO_50
2CCh PULL_CTRL_GPIO_51
2CDh IBUF_ST_GPIO_51
2CEh ODRIV_DS_GPIO_51
2D0h PULL_CTRL_GPIO_52
2D1h IBUF_ST_GPIO_52
2D2h ODRIV_DS_GPIO_52
2D4h PULL_CTRL_GPIO_53
2D5h IBUF_ST_GPIO_53
2D6h ODRIV_DS_GPIO_53
2D8h PULL_CTRL_GPIO_54
2D9h IBUF_ST_GPIO_54
2DAh ODRIV_DS_GPIO_54
