Serial Interface Register Maps
Table 2-2279. io_wrap Register Map (continued)
ADDRESS (Hex) D7 D6 D5 D4 D3 D2 D1 D0
2DCh PULL_CTRL_GPIO_55
2DDh IBUF_ST_GPIO_55
2DEh ODRIV_DS_GPIO_55
2E0h PULL_CTRL_GPIO_56
2E1h IBUF_ST_GPIO_56
2E2h ODRIV_DS_GPIO_56
2E4h PULL_CTRL_GPIO_57
2E5h IBUF_ST_GPIO_57
2E6h ODRIV_DS_GPIO_57
2E8h PULL_CTRL_GPIO_58
2E9h IBUF_ST_GPIO_58
2EAh ODRIV_DS_GPIO_58
2ECh PULL_CTRL_GPIO_59
2EDh IBUF_ST_GPIO_59
2EEh ODRIV_DS_GPIO_59
2F0h PULL_CTRL_GPIO_60
2F1h IBUF_ST_GPIO_60
2F2h ODRIV_DS_GPIO_60
2F4h PULL_CTRL_GPIO_61
2F5h IBUF_ST_GPIO_61
2F6h ODRIV_DS_GPIO_61
2F8h PULL_CTRL_GPIO_62
2F9h IBUF_ST_GPIO_62
2FAh ODRIV_DS_GPIO_62
2FCh PULL_CTRL_GPIO_63
2FDh IBUF_ST_GPIO_63
2FEh ODRIV_DS_GPIO_63
300h PULL_CTRL_GPIO_64
301h IBUF_ST_GPIO_64
302h ODRIV_DS_GPIO_64
304h PULL_CTRL_GPIO_65
305h IBUF_ST_GPIO_65
306h ODRIV_DS_GPIO_65
308h PULL_CTRL_GPIO_66
309h IBUF_ST_GPIO_66
30Ah ODRIV_DS_GPIO_66
30Ch PULL_CTRL_GPIO_67
30Dh IBUF_ST_GPIO_67
30Eh ODRIV_DS_GPIO_67
310h PULL_CTRL_GPIO_68
311h IBUF_ST_GPIO_68
312h ODRIV_DS_GPIO_68
314h PULL_CTRL_GPIO_69
315h IBUF_ST_GPIO_69
316h ODRIV_DS_GPIO_69
318h PULL_CTRL_GPIO_70
319h IBUF_ST_GPIO_70
31Ah ODRIV_DS_GPIO_70
31Ch PULL_CTRL_GPIO_71
31Dh IBUF_ST_GPIO_71
31Eh ODRIV_DS_GPIO_71
320h PULL_CTRL_GPIO_72
321h IBUF_ST_GPIO_72
322h ODRIV_DS_GPIO_72
324h PULL_CTRL_GPIO_73
325h IBUF_ST_GPIO_73
