ADC JESD Register Map
www.ti.com
372
SBAU337–May 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Serial Interface Register Maps
Table 2-501. adc_jesd Register Map (continued)
ADDRESS (Hex) D7 D6 D5 D4 D3 D2 D1 D0
87h 0 0 0 0 0 LINK0_JESD_TEST_SEQ_SEL
88h LINK0_INIT_O_MF_COUNTER[7:0]
89h 0 0 0 LINK0_INIT_O_MF_COUNTER[12:8]
8Ah 0 0 0 0 0 0 0
LINK0_ERR_CN
T_CLR
8Ch LINK1_DID
8Dh LINK1_ADJCNT LINK1_BID
8Eh 0 LINK1_ADJDIR LINK1_PHADJ 0 0 0 0 0
8Fh LINK1_SCR 0 0 LINK1_ILA_L_M1
90h LINK1_ILA_F_M1
91h LINK1_ILA_K_M1
92h LINK1_ILA_M_M1
93h LINK1_CS 0 LINK1_ILA_N_M1
94h LINK1_SUBCLASSV LINK1_ILA_NPRIME_M1
95h LINK1_JESDV LINK1_ILA_S_M1
96h LINK1_ILA_HD 0 0 LINK1_CF
97h LINK1_RES1
98h LINK1_RES2
9Bh 0 0 0 0 0 0 0
LINK1_JESD_IL
A_CONFIG_OV
ERRIDE
9Ch LINK1_K_M1
9Dh 0 0 0 0
LINK1_ENABLE
_F_CHAR_ON_
MFEND
LINK1_DISABLE
_F_CHAR
LINK1_DISABLE
_A_CHAR
LINK1_NO_LAN
E_SYNC
9Eh 0 0 0 0
LINK1_SYNC_F
_CTR_INCR_OV
R_EN
LINK1_SYNC_F_CTR_INCR_OVR_VAL
9Fh 0 0 0 0 0 LINK1_JESD_TEST_SEQ_SEL
A0h LINK1_INIT_O_MF_COUNTER[7:0]
A1h 0 0 0 LINK1_INIT_O_MF_COUNTER[12:8]
A2h 0 0 0 0 0 0 0
LINK1_ERR_CN
T_CLR
A4h LINK2_DID
A5h LINK2_ADJCNT LINK2_BID
A6h 0 LINK2_ADJDIR LINK2_PHADJ 0 0 0 0 0
A7h LINK2_SCR 0 0 LINK2_ILA_L_M1
A8h LINK2_ILA_F_M1
A9h LINK2_ILA_K_M1
AAh LINK2_ILA_M_M1
ABh LINK2_CS 0 LINK2_ILA_N_M1
ACh LINK2_SUBCLASSV LINK2_ILA_NPRIME_M1
ADh LINK2_JESDV LINK2_ILA_S_M1
AEh LINK2_ILA_HD 0 0 LINK2_CF
AFh LINK2_RES1
B0h LINK2_RES2
B2h
LINK2_JESD_IL
A_CONFIG_OV
ERRIDE 0 0 0 0 0 0 0
B4h LINK2_K_M1
B5h 0 0 0 0
LINK2_ENABLE
_F_CHAR_ON_
MFEND
LINK2_DISABLE
_F_CHAR
LINK2_DISABLE
_A_CHAR
LINK2_NO_LAN
E_SYNC
B6h 0 0 0 0
LINK2_SYNC_F
_CTR_INCR_OV
R_EN
LINK2_SYNC_F_CTR_INCR_OVR_VAL
B7h 0 0 0 0 0 LINK2_JESD_TEST_SEQ_SEL
B8h LINK2_INIT_O_MF_COUNTER[7:0]
B9h 0 0 0 LINK2_INIT_O_MF_COUNTER[12:8]
BAh 0 0 0 0 0 0 0
LINK2_ERR_CN
T_CLR
BCh 0 0 0 LID0
