configure stpd mode
ExtremeWare Software 7.3.0 Command Reference Guide 1011
configure stpd mode
configure stpd <spanning tree name> mode [dot1d | dot1w]
Description
Configures the operational mode for the specified STP domain.
Syntax Description
Default
Operates in 802.1d mode.
Usage Guidelines
If you configure the STP domain in 802.1d mode, the rapid reconfiguration mechanism is disabled.
If you configure the STP domain in 802.1w mode, the rapid reconfiguration mechanism is enabled.
Example
The following command configures STPD s1 to enable the rapid reconfiguration mechanism and operate
in 802.1w mode:
configure stpd s1 mode dot1w
History
This command was first available in ExtremeWare 7.1.
Platform Availability
This command is available on all platforms.
spanning tree name Specifies an STPD name on the switch.
dot1d Specifies the STPD mode of operation to be 802.1d.
dot1w Specifies the STPD mode of operation to be 802.1w, and rapid configuration
is enabled.
