1618 ExtremeWare Software 7.3.0 Command Reference Guide
ATM Commands
configure atm add pvc
configure atm add pvc <vpi/vci> encap [l2 | ip peer-ipaddress <ipaddress>]
vlan <vlan name> ports <portlist>
Description
This command configures PVC on an ATM port.
Syntax Description
Default
None.
Usage Guidelines
Before packets can be forwarded over ATM ports, at least one PVC must be configured on the port and
mapped to a VLAN. Each PVC must be mapped to one or more VLANs and each mapping must be
designated to use the bridged protocol encapsulation or the routed protocol encapsulation. Both
encapsulations can be simultaneously used on a PVC as long as they are associated with different
VLANs.
The PVC is identified by the specified vpi and vci parameters. The vpi parameter is an integer in the
range of 0 through 15. The
vci parameter is an integer in the range of 17 through 4095. Both
parameters are defined in RFC 2648/1483.
The encap parameter indicates the type of encapsulation that is to be used on the PVC for traffic from
the associated VLAN. The
l2 keyword is an abbreviation for Layer-2 and indicates the LLC
Encapsulation for Bridged Protocols (defined in RFC 2684). The
ip keyword indicates that the VLAN
will carry only routed IP traffic and that the LLC Encapsulation for Routed Protocols (defined in RFC
2684) should be used.
Example
The following command configures PVC 5/101 on ATM port 1:1 on a VLAN named accounting .
configure atm add pvc 5/102 encap l2 vlan accounting port 1:1
vpi Specifies the VPI parameter as an integer.
The valid VPI range is from 0 to 15.
vci Specifies the VCI parameter as an integer.
The valid VCI range is from 17 to 4095
encap Specifies the type of encapsulation to be used.
l2 Specifies Layer-2 encapsulation.
ip peer-ipaddress Specifies that the VLAN will carry only routed IP traffic and that LLC
encapsulation should be used.
vlan name Specifies a VLAN name.
portlist Specifies list of ports or slots and ports. May be in the form 1, 2, 3-5,
2:5, 2:6-2:8.
