This can be established by globally assigning all UART interrupts to the
same interrupt priority. For more information, see Appendix B, Peripheral
Interrupt Control.
There is also a shadow register,
UART0IIRSH. This register allows programs
to read the contents of the corresponding main register without affecting
the status of the UART.
Figure A-139. UART0IIRSH Register
Table A-130. UART0IIRSH Register Bit Descriptions (RO)
Bit Name Description
0 UARTNOINT Pending Interrupt. When UARTNOINT bit cleared it signals that
an interrupt is pending.
0 = Interrupt pending
1 = No interrupt pending (default)
3–1
(ROC
1
)
1 These bits are read-only in the UARTxLRSH (shadow) register.
UARTISTAT In the Order of Interrupt Priority, Highest First.
011 = Receive line status. Read UART_LSR to clear interrupt
request.
100 = Address detect. Read RBR to clear interrupt request.
010 = Receive data ready. Read UART RBR to clear interrupt
request.
001 = UART_THR empty. Write UART_THR or read UART_IIR
to clear interrupt request, when priority = 4.
000 = UART THR & TSR empty (TEMT = transmit complete).
Write UART_THR or read UART_IIR to clear interrupt request,
when priority = 5. In the case where both interrupts are signalling,
the UARTxIIR register reads 0x06. When a UART interrupt is
pending, the interrupt service routine (ISR) needs to clear the
interrupt latch explicitly.
UARTISTAT (3–1)
In the order of interrupt priority, highest first
Pending Interrupt
UARTNOINT
