ADSP-214xx SHARC Processor Hardware Reference 12-1
12 ASYNCHRONOUS SAMPLE
RATE CONVERTER
The asynchronous sample rate converter (SRC) block is used to perform
synchronous or asynchronous sample rate conversion across independent
stereo channels, without using any internal processor resources. Further-
more, the SRC is used to clean up audio data from jittery clock sources
such as the S/PDIF receiver. The SRC specifications are listed in
Table 12-1.
Table 12-1. SRC Specifications
Feature Availability
Connectivity
Multiplexed Pinout No
SRU DAI Required Yes
SRU DAI Default Routing No
SRU2 DPI Required No
SRU2 DPI Default Routing N/A
Interrupt Control Yes
Protocol
Master Capable No
Slave Capable Yes
Transmission Simplex Yes
Transmission Half Duplex No
Transmission Full Duplex No
