Functional Description
9-26 ADSP-214xx SHARC Processor Hardware Reference
Pin Buffer Input
DAI group D or DPI group B are used to specify any signals that are
driven off-chip by the pin buffers. A pin buffer input (PBxx_I) is driven as
an output from the processor when the pin buffer enable is set (= 1).
Each physical pin (connected to a bonded pad) may be connected via the
SRU to any of the outputs of the DAI/DPI peripherals, based on the bit
field values. The SRU also may be used to route signals that control the
pins in other ways. Many signals may be configured for use as control
signals.
Any of the DAI/DPI pins may also be considered general-purpose
input/output (GPIO) pins. Each of the DAI pins can also be set to drive a
high or low logic level to assert signals. They can also be used as DAI/DPI
interrupt sources.
On the DAI, two dedicated input pin buffers are allowed to invert the
input level on the pins by a bit setting. However this only applies if the
buffer is not assigned to itself.
Pin Buffer Enable
DAI group F or DPI group C signals are used to specify whether each
DAI/DPI pin is used as an output or an input by setting the source for the
pin buffer enables. When a pin buffer enable (PBENxx_I) is set (= 1), the
C–Pin Buffer
Enable
DPI Pin Buffer Enable Timer1–0
SPI (MOSI, MISO, DS, CLK)
SPIB (MOSI, MISO, DS, CLK)
UART0 TX
FLAG15–4
TWI (clock, data)
MISCB8–0
Logic level high
Logic level low
Table 9-5. DPI Routing Capabilities (Cont’d)
