18-2 ADSP-214xx SHARC Processor Hardware Reference
Features
The RTC interface has the following features.
• Provides a 1 Hz clock with Second, Minute, Hour and Day Coun-
ter (0 to 32767 days)
• Alarm Feature available with time of day interrupt
• Operates on a dedicated supply from an external 3.3 V battery
• Stopwatch function available
• Standard two pin interface with external 32.768 KHz crystal, 6 pF
capacitor on each pin and 100 MΩ resistor between the pins
• RTC Power switches to that of I/O Supply when chip is powered
on, saving battery life
• Calibration Feature available to correct time once a day; applica-
tion can use
RTCXTALIN pin to determine calibration settings
Core Data Access N/A
DMA Data Access N/A
DMA Channels N/A
DMA Chaining N/A
Boot Capable No
Local Memory No
Clock Operation f
PCLK
Table 18-1. RTC Specifications (Cont’d)
