SDRAM Controller (ADSP-2147x/ADSP-2148x)
3-28 ADSP-214xx SHARC Processor Hardware Reference
Row Address Width (SDRAW). These bits in the
SDCTL register deter-
mine the row width of the SDRAM. The SDRAW bits can be programmed
for row widths of 8 to 15.
Column Address Width (SDCAW). The SDRAM memory control regis-
ter also includes external bank specific programmable parameters. The
external bank can be configured for a different SDRAM size. The
SDRAM controller determines the internal SDRAM page size from the
X16DE and SDCAW parameters. Page sizes of 128, 256, 512, 1K, 2K
words are supported.
16-Bit Address Mapping
Even if the external data width is 16 bits, the processor supports only
32-bit data accesses. If X16DE is enabled (=1) the SDC performs two 16-bit
accesses to get and place 32-bit data. The SDC takes the IA address and
appends one extra bit to the LSB to generate the address externally.
In the following sections and in Table 3-7 through Table 3-10, the map-
ping of internal addresses to the external addresses is discussed. The
mapping of the addresses depends on the address mode (SDAD-
DRMODE) on row address width (SDRAW), and on column address
width (SDCAW).
The X16DE bit must always be set.
For example, if the processor core requests address 0x200–0000 for a
32-bit access, the SDC performs two 16-bit accesses at 0x400–0000 and
0x400–0001, using
MS0 to get one 32-bit data word. The column and row
addresses seen by 16-bit SDRAMs is shown in Table 3-7 where
SDADDRMODE = 1, X16DE = 1, SDRAW2–0 = 101 (13 bits), and SDCAW1–0 = 10
(10 bits).
