SDRAM Controller (ADSP-2147x/ADSP-2148x)
3-18 ADSP-214xx SHARC Processor Hardware Reference
• Supports up to 254M words of SDRAM memory
• No-burst mode (BL = 1) with sequential burst type
• Open page policy—any open page is closed only if a new access in
another page of the same bank occurs
• Supports multibank operation within the SDRAM
• Uses a programmable refresh counter to coordinate between vary-
ing clock frequencies and the SDRAM’s required refresh rate
• Provides multiple timing options to support additional buffers
between the processor and SDRAM
• Allows independent auto-refresh while the asynchronous memory
interface (AMI) has control of the external port
• Supports self-refresh mode for power savings
• Predictive data accesses for higher read data throughput (read
optimization)
• Supports external instruction fetch in bank 0 for ISA and VISA
operation
• Supports 64-bit SIMD mode by the core
• Supports dual data instruction type 1
Functional Description
The SDRAM control signals (MSx, SDCKE, SDRAS, SDCAS, SDWE) define vari-
ous operation modes to the SDRAM. Table 3-5 provides a reference to
these commands and the pin state for each one.
The configuration is programmed in the SDCTL register. The SDRAM con-
troller can hold off the processor core or DMA controller with an
