Programming Model
16-22 ADSP-214xx SHARC Processor Hardware Reference
3. Set the
TIMEN bit. The timer performs boundary exception checks
on the period and width values:
If (width == 0 or Period < width or period == width) both
the OVF_ERR and IRQ bits are set.
If there are no exceptions, the width value is loaded into the
counter and it starts counting.
The timer produces PWM waveform with a period of 2 x period
and a width of 2 x width.
When 2 x width expires, the counter is loaded with
2x(period – width) and continues counting.
When 2 x period expires, the counter is loaded with 2 x
width value again and the cycle repeats.
When the width or period expires, the IRQ bit (if enabled) is
set depending on the PRDCNT bit.
When IRQ is sensed, read the status register (TMxSTAT) and
perform the appropriate “write-one” to clear.
WDTH_CAP Mode
Use the following procedure to configure and run the timer in
WDTH_CAP out mode.
1. Reset the
TIMEN bit and set the configuration mode to 10 to select
WDTH_CAP operation. This configures the
TIMERx_I pin as an
input pin with its polarity determined by the PULSE bit.
The timer measures a positive active pulse width at the
TIMERx_I pin.
The timer measures a negative active pulse width at the
TIMERx_I pin.
