SDRAM Controller (ADSP-2147x/ADSP-2148x)
3-38 ADSP-214xx SHARC Processor Hardware Reference
Data Mask
The SDRAM controller provides one
DQM pin (SDDQM), all SDRAM DQM
pins could be connected to SDDQM pin . The SDDQM pin is driven high from
reset deassertion until SDRAM initialization completes, after that it’s
driven low irrespective of whether any accesses occur.
Note that some manufacturer’s require keeping DQM high during the
power-up initialization sequence.
Resetting the Controller
Like any other peripheral, the SDRAM controller can be reset by a hard or
a soft reset. A hard reset puts the PLL in bypass mode where the SDRAM
clock runs at a lower frequency.
A soft reset also causes data loss, and programs need to re-initialize
SDRAM before it can be used again.
Running reset (RESETOUT pin as an input) does not reset the
SDRAM controller.
Operating Modes
The following sections provide on the operating modes of the SDRAM
interface.
Parallel Connection of SDRAMs
To specify a SDRAM system, multiple possibilities are given based on the
different memory sizes. For a 16-bit I/O capability, the following can
configured.
• 2 x 16-bit/page 512 words
• 4 x 8-bit/page 1k words
