DDR2 DRAM Controller (ADSP-2146x)
3-66 ADSP-214xx SHARC Processor Hardware Reference
Table 3-15 shows
DDR2ADDRMODE = 1, DDR2RAW = 100 (12), DDR2CAW = 11
(11), DDR2BC = 01(four banks).
Refresh Rate
The DDR2 refresh rate control register (DDR2RRC) provides a flexible
mechanism for specifying the auto-refresh timing. The DDR2 controller
provides a programmable refresh counter which has a period based on the
value programmed into the RDIV field of this register, which coordinates
the supplied clock rate with the DDR2 device’s required refresh rate.
Table 3-15. 16-bit Address Mapping (4 Banks, Bank Interleaving)
SHARC Pin Column Address Row Address Bank Address DDR2 Pin
DDR2_BA1 IA[23] BA[1]
DDR2_BA0 IA[22] BA[0]
DDR2_ADDR[13]
DDR2_ADDR[12] A[12]
DDR2_ADDR[11] IA[9] IA[21] A[11]
DDR2_ADDR[10] IA[20] A[10]
DDR2_ADDR[9] IA[8] IA[19] A[9]
DDR2_ADDR[8] IA[7] IA[18] A[8]
DDR2_ADDR[7] IA[6] IA[17] A[7]
DDR2_ADDR[6] IA[5] IA[16] A[6]
DDR2_ADDR[5] IA[4] IA[15] A[5]
DDR2_ADDR[4] IA[3] IA[14] A[4]
DDR2_ADDR[3] IA[2] IA[13] A[3]
DDR2_ADDR[2] IA[1] IA[12] A[2]
DDR2_ADDR[1] IA[0] IA[11] A[1]
DDR2_ADDR[0] 1/0 IA[10] A[0]
