ADSP-214xx SHARC Processor Hardware Reference 3-65
External Port
Table 3-14 shows
DDR2ADDRMODE = 1, DDR2RAW = 100 (12), DDR2CAW = 10
(10), DDR2BC = 10 (eight banks).
DDR2_ADDR[1] IA[0] IA[13] A[1]
DDR2_ADDR[0] 1/0 IA[12] A[0]
Table 3-14. 16-bit Address Mapping (8 Banks, Bank Interleaving)
SHARC Pin Column Address Row Address Bank Address DDR2 Pin
DDR2_BA2 IA[23] BA[2]
DDR2_BA1 IA[22] BA[1]
DDR2_BA0 IA[21] BA[0]
DDR2_ADDR[12] A[12]
DDR2_ADDR[11] IA[20] A[11]
DDR2_ADDR[10] IA[19] A[10]
DDR2_ADDR[9] IA[8] IA[18] A[9]
DDR2_ADDR[8] IA[7] IA[17] A[8]
DDR2_ADDR[7] IA[6] IA[16] A[7]
DDR2_ADDR[6] IA[5] IA[15] A[6]
DDR2_ADDR[5] IA[4] IA[14] A[5]
DDR2_ADDR[4] IA[3] IA[13] A[4]
DDR2_ADDR[3] IA[2] IA[12] A[3]
DDR2_ADDR[2] IA[1] IA[11] A[2]
DDR2_ADDR[1] IA[0] IA[10] A[1]
DDR2_ADDR[0] 1/0 IA[9] A[0]
Table 3-13. 16-bit Address Mapping (4 Banks, Page Interleaving) (Cont’d)
SHARC Pin Column Address Row Address Bank Address DDR2 Pin
