ADSP-214xx SHARC Processor Hardware Reference A-63
Registers Reference
Peripheral Registers
The registers in the following sections are used for the peripherals that are
not routed through the signal routing units (SRU, SRU2).
Link Port Registers
The following sections describe the link port status and control registers.
Control Register (LCTLx)
Figure A-28 and Table A-33 describe the bit fields within this register.
25 (RO) DIRS DMA Transfer Direction Status.
0 = DMA direction is external reads
1 = DMA direction is external writes
This is useful for delay line DMA where the transfer direction
changes with the state of the DMA state machine.
For standard DMA, DIRS reflects the state of the TRAN bit.
31–26 Reserved
Table A-32. External Port DMA Register Bit Descriptions (RW) (Contd)
Bit Name Description
www.BDTIC.com/ADI
