ADSP-214xx SHARC Processor Hardware Reference 10-1
10 SERIAL PORTS
The processors have eight independent, synchronous serial ports
(SPORTs) that provide an I/O interface to a wide variety of peripheral
devices. They are called SPORT0, SPORT1, SPORT2, SPORT3,
SPORT4, SPORT5, SPORT6, and SPORT7. Each SPORT has its own
set of control registers and data buffers. With a range of clock and frame
synchronization options, the SPORTs allow a variety of serial communi-
cation protocols and provide a glueless hardware interface to many
industry-standard data converters and codecs. The interface specifications
are shown in Table 10-1.
Table 10-1. Serial Port Specifications
Feature SPORT7–0[AB]
Connectivity
Multiplexed Pinout No
SRU DAI Required Yes
SRU DAI Default Routing Yes
SRU2 DPI Required No
SRU2 DPI Default Routing N/A
Interrupt Control Yes
Protocol
Master Capable Yes
Slave Capable Yes
Transmission Simplex Yes
Transmission Half Duplex Yes
