ADSP-214xx SHARC Processor Hardware Reference 12-17
Asynchronous Sample Rate Converter
ratio. Hard mute, soft mute, and auto mute only control the muting of
the input data to the SRC.
Table 12-4 provides an overview of SRC interrupts.
Debug Features
The asynchronous sample rate converter allow the bypass mode. When the
BYPASS bit is set (=1), the input data bypasses the sample rate converter
and is sent directly to the serial output port. This mode can be used for
testing both ports when the input and output sample rates are at the same
frequency, therefore both in- and output ports can be routed to the same
serial clock and frame sync.
Effect Latency
The total effect latency is a combination of the write effect latency (core
access) plus the peripheral effect latency (peripheral specific).
Write Effect Latency
For details on write effect latency, see the SHARC Processor Programming
Reference.
Table 12-4. SRC Interrupt Overview
Interrupt Source Interrupt Condition Interrupt
Completion
Interrupt
Acknowledge
Default IVT
DAI SRC
RX/TX (I2S, left/right
justified, TDM, 4
channels)
– Mute out asserted
(SRC init, SRC sample
rate change)
Read-to-clear
DAI_IRPTL_x
+ RTI instruction
P0I, P12I
