Power Management
22-10 ADSP-214xx SHARC Processor Hardware Reference
The advantage of the delayed core reset is that the PLL can be reset
any number of times without having to power down the system. If
there is a brownout situation, the external watchdog circuit only
has to control the RESET signal. For more information on device
power-up, see the appropriate product data sheet.
Power Management
The processor allows systems to shut down the clock to the different mod-
ules in the peripheral domain in order to save power if the peripherals are
not required by the application.
Peripherals
All internal clocks to the peripherals are enabled by default. However,
they can be disabled using the PMCTL1 register.
The PMCTL1 register allow programs to disable the clock source to a partic-
ular processor peripheral (for example the external port) to further
conserve power. Programs can use the PMCTL1 register to turn the specific
peripheral off after the application no longer needs it. For a complete reg-
ister description, see “ADSP-2146x Power Management Registers” on
page A-6 and “ADSP-2147x/ADSP-2148x Power Management Registers”
on page A-12.
DAI Routing Unit
To further preserve power, the clock to the DAI routing unit can be dis-
abled using the DAIOFF bit in the PMCTL1 register. If, for example, a system
requires the SPORTs, the DAI system routing can be configured and then
bit 4 can be cleared to disable the routing block. Note that the SPORT
continues to operate as long as the SPORT clocks themselves are not shut
down.
