ADSP-214xx SHARC Processor Hardware Reference A-189

Registers Reference

Mute Register (SRCMUTE)

This register connects an SRCx mute input and output when the

SRC0_MUTE_ENx bit is cleared (=0). This allows SRCx to automatically

mute input while the SRC is initializing (0 = automatic muting and

1 = manual muting). Bit 0 controls SRC0, bit 1 controls SRC1, bit 2 con-

trols SRC2, and bit 3 controls SRC3.

Ratio Registers (SRCRATx)

These registers report the mute and I/O sample ratio as follows: the

SRCRAT0 register reports for SRC0 and SRC1 and the SRCRAT1 register

reports the mute and I/O sample ratio for SRC2 and SRC3 (X = SRC0

and SRC1, Y = SRC2 and SRC3). The registers are shown in Figure A-99

and Figure A-100 and described in Table A-97.

30 Reserved

31 SRCy_ENABLE SRC Enable. Enables SRC 1, 3. When (set = 1), or when the

sample rate (frame sync) between the input and output changes,

the SRC begins its initialization routine where;

1) MUTE_OUT is asserted,

2) soft mute control counter for input samples is set to maxi-

mum attenuation (–144 dB).

Note that SRC power-up completion is finished by clearing the

SRCx_MUTEOUT bit in SRCRATx register. Writes to the

SRCCTLx register should be at least one cycle before setting the

SRCx_ENABLE. When setting and clearing this bit, it should

be held low for a minimum of 5 PCLK cycles. Programs should

disable the SRC when changing modes.

Table A-96. SRCCTLx Register Bit Descriptions (RW) (Cont’d)

Bit Name Description
