Register Listing
A-282 ADSP-214xx SHARC Processor Hardware Reference
MT6CCS3 0x4810 SPORT 6 TDM TX Compand Select, CH127–96 0x0
MR7CCS0 0x4811 SPORT 7 TDM RX Compand Select, CH31–0 0x0
MR7CCS1 0x4812 SPORT 7 TDM RX Compand Select, CH63–32 0x0
MR7CCS2 0x4813 SPORT 7 TDM RX Compand Select, CH95–64 0x0
MR7CCS3 0x4814 SPORT 7 TDM RX Compand Select, CH127–96 0x0
SPMCTL7 0x4817 SPORT 7 TDM Control 0x0
IISP6A 0x4840 Internal Memory DMA Address 0x0
IMSP6A 0x4841 Internal Memory DMA Access Modifier 0x0
CSP6A 0x4842 Contains Number of DMA Transfers Remaining 0x0
CPSP6A 0x4843 Points to Next DMA Parameters 0x0
IISP6B 0x4844 Internal Memory DMA Address 0x0
IMSP6B 0x4845 Internal Memory DMA Access Modifier 0x0
CSP6B 0x4846 Contains Number of DMA Transfers Remaining 0x0
CPSP6B 0x4847 Points to Next DMA Parameters 0x0
IISP7A 0x4848 Internal Memory DMA Address 0x0
IMSP7A 0x4849 Internal Memory DMA Access Modifier 0x0
CSP7A 0x484A Contains Number of DMA Transfers Remaining 0x0
CPSP7A 0x484B Points to Next DMA Parameters 0x0
IISP7B 0x484C Internal Memory DMA Address 0x0
IMSP7B 0x484D Internal Memory DMA Access Modifier 0x0
CSP7B 0x484E Contains Number of DMA Transfers Remaining 0x0
CPSP7B 0x484F Points to Next DMA Parameters 0x0
TXSP6A 0x4860 SPORT 6A Transmit Data 0x0
RXSP6A 0x4861 SPORT 6A Receive Data 0x0
TXSP6B 0x4862 SPORT 6B Transmit Data 0x0
RXSP6B 0x4863 SPORT 6B Receive Data 0x0
TXSP7A 0x4864 SPORT 7A Transmit Data 0x0
Register Mnemonic Address Description Reset
