ADSP-214xx SHARC Processor Hardware Reference A-287
Registers Reference
DAI_STAT0 0x24B8 IDP Status 0x0
DAI_STAT1 0x24BA IDP Status 0x0
Input Data Port DMA Parameter Registers
IDP_DMA_I0 0x2400 IDP DMA Channel 0 Index 0x0
IDP_DMA_I1 0x2401 IDP DMA Channel 1 Index 0x0
IDP_DMA_I2 0x2402 IDP DMA Channel 2 Index 0x0
IDP_DMA_I3 0x2403 IDP DMA Channel 3 Index 0x0
IDP_DMA_I4 0x2404 IDP DMA Channel 4 Index 0x0
IDP_DMA_I5 0x2405 IDP DMA Channel 5 Index 0x0
IDP_DMA_I6 0x2406 IDP DMA Channel 6 Index 0x0
IDP_DMA_I7 0x2407 IDP DMA Channel 7 Index 0x0
IDP_DMA_I0A 0x2408 IDP DMA Channel 0 Index A for Ping Pong DMA 0x0
IDP_DMA_I1A 0x2409 IDP DMA Channel 1 Index A for Ping Pong DMA 0x0
IDP_DMA_I2A 0x240A IDP DMA Channel 2 Index A for Ping Pong DMA 0x0
IDP_DMA_I3A 0x240B IDP DMA Channel 3 Index A for Ping Pong DMA 0x0
IDP_DMA_I4A 0x240C IDP DMA Channel 4 Index A for Ping Pong DMA 0x0
IDP_DMA_I5A 0x240D IDP DMA Channel 5 Index A for Ping Pong DMA 0x0
IDP_DMA_I6A 0x240E IDP DMA Channel 6 Index A for Ping Pong DMA 0x0
IDP_DMA_I7A 0x240F IDP DMA Channel 7 Index A for Ping Pong DMA 0x0
IDP_DMA_I0B 0x2418 IDP DMA Channel 0 Index B for Ping Pong DMA 0x0
IDP_DMA_I1B 0x2419 IDP DMA Channel 1 Index B for Ping Pong DMA 0x0
IDP_DMA_I2B 0x241A IDP DMA Channel 2 Index B for Ping Pong DMA 0x0
IDP_DMA_I3B 0x241B IDP DMA Channel 3 Index B for Ping Pong DMA 0x0
IDP_DMA_I4B 0x241C IDP DMA Channel 4 Index B for Ping Pong DMA 0x0
IDP_DMA_I5B 0x241D IDP DMA Channel 5 Index B for Ping Pong DMA 0x0
IDP_DMA_I6B 0x241E IDP DMA Channel 6 Index B for Ping Pong DMA 0x0
IDP_DMA_I7B 0x241F IDP DMA Channel 7 Index B for Ping Pong DMA 0x0
Register Mnemonic Address Description Reset
